Home > Accessory > Protective film
FMPF.055.100 FMPF.055.100 FMPF.055.100 FMPF.055.100 FMPF.055.100

FMPF.055.100

$120.00Excl.tax Excl. Shipping costs
ADD TO CART
TEAMS
Dedicated service teams.
KNOW-HOW
More than 25 years of experience
QUALITY
Outstanding quality
SERVICE
24-hour quick response
  • Information
  • Quick Application and Removal
    Our anti-marring films are designed for rapid integration into any press brake operation. They feature either a self-adhesive backing for secure attachment to the bottom die or are designed to lay securely in the V-groove. They can be quickly applied and removed without leaving residue on the die or the workpiece. This user-friendly characteristic ensures that the speed gained from using CNC press brakes is not compromised by time-consuming tool setup or cleanup, thus maintaining high production efficiency and uptime.
    Remote Support
    Choose the Right Film Thickness
    When selecting the appropriate protective film, consider the material thickness being bent and the required tonnage. Thicker films offer more cushioning and abrasion resistance but may slightly affect the required bending force and angle compensation. For heavy-gauge or high-tonnage jobs, a durable, thicker grade is essential. For light-gauge, highly polished materials, a thinner film may suffice. Always check the film manufacturer's specifications for compatibility with your V-die opening and the material's properties to optimize forming accuracy.
    Remote Support
  • Air Bending Force
  •
    Air bending force
    Required press force at 90° air bending, force in ton/mtr.

    The charts below give the appropriate tonnage to air bend mild steel.

    Bending force for other metals:
    Soft aluminium Tons per unit length x 50%
    Aluminium alloys heat treated Tons per unit length x 100%
    Stainless Tons per unit length x 150%




  • Items
  • Order：

    Minimum order is $20.00.


    Special Orders：

    All special orders are non-cancelable, non-returnable, and non-refundable.


    Payment Terms：

    Terms are net 10 days. Catalog prices are subject to change without notice.


    Freight：

    Orders are shipped F.O.B. from our manufacturing facility. (International Shipments are Incoterms: Ex Works).


    Order Cancellation：

    In the event an order is cancelled, an additional charge will be assessed to cover the cost of labor and material.


    Returned Material：

    A handling/restocking fee will be applied to all products returned for credit. A return authorization number and shipping instructions must be obtained in advance before an item can be returned.

    Claims：

    All claims or product shortages must be made within 30 days of the invoice date.
