Shearing blade

Name: Shearing blade
Brand: FABMAX
Availability: InStock
Rating: 5 (1 reviews)

$0.00Excl.tax Excl. Shipping costs

ADD TO CART

TEAMS

Dedicated service teams.

KNOW-HOW

More than 25 years of experience

QUALITY

Outstanding quality

SERVICE

24-hour quick response

Information

Fabmax has been producing shear blades for more than 20 years, using high quality steel to guarantee reliability and wealresistance.
Each product is studied on customer's needs: material to cut, holes and hardening upon your requestBlades with 1.2 or 4 cutting edges with threaded holes or dimpled holes.

Available sizes mm (in)
50(1.97)	50(2.17)	60(2.36)	65(2.56)	70(2.76)	75(2.95)	80(3.15)	85(3.35)	90(3.54)	100(3.94)
50x10(1.97x 039)
50x11(1.97x0.43)
50x12(1.97x0.47)	55x12(2.17x0.47)	60x12(2.36x0.51)
50x13(1.97x0.51)	55x13(2.17x0.51)	60x13(2.36x0.51)	65x13(2.56x0.51)	70x13(2.76x0.51)
50x14(1.97x0.55)	55x14(2.17x0.55)	60x14(2.36x0.55)	65x14(2.56x0.55)	70x14(2.76x0.55)
50x15(1.97x0.59)	55x15(2.17x0.59)	60x15(2.36x0.59)	65x15(2.56x0.59)	70x15(2.76x0.59)	75x15(2.95x0.59)
	55x16(2.17x0.63)	60x16(2.36x0.63)	65x16(2.56x0.63)	70x16(2.76x0.63)	75x16(2.95x0.63)
	55x17(2.17x0.67)	60x17(2.36x0.67)	65x17(2.56x0.67)	70x17(2.76x0.67)	75x17(2.95x0.67)
	55x18(2.17x0.71)	60x18(2.36x0.71)	65x18(2.56x0.71)	70x18(2.76x0.71)	75x18(2.95x0.71)	80x18(3.15x0.71)	85x18(3.35x0.71)
	55x19(2.17x0.75)	60x19(2.36x0.75)	65x19(2.56x0.75)	70x19(2.76x0.75)	75x19(2.95x0.75)	80x19(3.15x0.75)	85x19(3.35x0.75)
	55x20(2.17x0.79)	60x20(2.36x0.79)	65x20(2.56x0.79)	70x20(2.76x0.79)	75x20(2.95x0.79)	80x20(3.15x0.79)	85x20(3.35x0.79)	90x20(3.54x0.79)	100x20(3.94x0.79)
					75x21(2.95x0.83)	80x21(3.15x0.83)	85x21(3.35x0.83)	90x21(3.54x0.83)
					75x22(2.95x0.87)	80x22(3.15x0.87)	85x22(3.35x0.87)	90x22(3.54x0.87)
					75x23(2.95x0.91)	80x23(3.15x0.91)	85x23(3.35x0.91)	90x23(3.54x0.91)
					75x24(2.95x0.94}	80x24(3.15x0.94)	85x24(3.35x0.94)	90x24(3.54x0.94)
					75x25(2.95x0.98)	80x25(3.15x0.98)	85x25(3.35x0.98)	90x25(3.54x0.98)	100x25(3.94x0.98)
									100x26(3.94x1.02)
									100x27(3.94x1.06)
									100x28(3.94x1.10)
									100x29(3.94x1.14)
									100x30(3.94x1.18)

Standard tolerances
Hardeness	Height	Width	Parallelism
±1HRC	±0.5mm	±0.2mm	±0.03mm

Items
Order：

Minimum order is $20.00.

Special Orders：

All special orders are non-cancelable, non-returnable, and non-refundable.

Payment Terms：

Terms are net 10 days. Catalog prices are subject to change without notice.

Freight：

Orders are shipped F.O.B. from our manufacturing facility. (International Shipments are Incoterms: Ex Works).

Order Cancellation：

In the event an order is cancelled, an additional charge will be assessed to cover the cost of labor and material.

Returned Material：

A handling/restocking fee will be applied to all products returned for credit. A return authorization number and shipping instructions must be obtained in advance before an item can be returned.

Claims：

All claims or product shortages must be made within 30 days of the invoice date.

Description
Optimal Tooling Longevity

The primary advantage of high-quality Shearing Blades lies in their guaranteed cutting precision and exceptional tooling longevity. Manufactured from specialized, high-alloy tool steel (such as D2 or HSS), these blades maintain a sharp edge for extended periods, reducing the frequency of necessary blade regrinding. This ensures consistent, burr-free cuts across materials ranging from thin gauge to heavy plate. Choosing superior shearing machine blades is critical for minimizing material waste and achieving the tight cut tolerances required in high-volume sheet metal fabrication.

Maximized Efficiency

The design and material composition of our Shearing Blades offer significant cost and efficiency advantages. Precisely engineered blade geometry reduces the required shearing force, lowering stress on the shearing machine mechanics. Furthermore, the robust durability translates directly into reduced maintenance downtime and fewer blade replacements. Investing in premium press brake tools like these ensures optimal performance and a lower Total Cost of Ownership, guaranteeing reliable, high-speed material processing.
